Spindle Kits
WHEEL AND SWING ARM
Full and partial spindle kits for Triumph, BSA and Norton front / rear wheels & swing arms. Complete with nuts, spacers, washers and adjusters as fitted to your machine originally.
Note: Stainless Classics has been providing spindles and associated spindle components for many years, you can purchase complete kits or partial kits as needed below. Every component is also available separately if you require it - just search for the part number or name. If you can't find what you need, just get in touch with us via the Contacts page.
BSA up to 1970 Rear Spindle Kit
Complete rear spindle kit suitable for BSA B44, B25, and B40 models up to 1970. Note 71 model spindles and accessories also available.
Set comprises of: Rear spindle (41-6098), fixed spindle (41-6032), fixed spindle nut (68-6066), spacer, inner speedo drive side (41-6019), outer spacer (41-6082). Optionally with rear chain adjusters.
Select the type required, with or without adjusters.
BSA A7 / A10 Ariel Type Rear Hub Spindle Kit
Complete rear spindle kit suitable for BSA A7 / A10 models fitted with Ariel type hubs, in and around 1958 (for 1 year only).
Set comprises of: Ariel hub main spindle (42-6071), Ariel fixed spindle (42-6076), slip collar (42-6075), thick washer spindle side (42-6074), thick washer nut side (42-6078), rear spindle nut (42-6077) thread size 11/16"-20, and 4-off sprocket nut (42-6095), thread size 7/16-BSF.
BSA A7 A10 Hollow Swingarm Spindle Set
BSA A7 & A10 Rear Spindle Set
USEFUL INFORMATION
There two other spindle sets which were fitted to A10’s / A7’s, depending upon when they left the factory, please check before ordering.
- Some mid 1950’s models had the same set up as the B31 and Gold star DB 32 and DB34. (See Gold Star Rear)
- Around 1958, BSA used up some excess Ariel alloy hubs (front and rear) and these models had spindles modelled on the Ariel ones, but were shorter. You can find these by searching for “ BSA Ariel, front or rear”
Triumph Swingarm Spindle Kit 1967-on
Triumph Rear Spindle Kit 1968 on – 9-7/8″
Early Triumph Front Spindle Set – 7-1/4″
Triumph Conical Hub Front Spindle Set 8-1/4″
Triumph T140V TR7RV Rear Spindle Set
Triumph Swingarm Spindle Kit 1970
Triumph Swingarm Spindle Kit
